• Lead lined model for hospital x-ray room doors with double row of fasteners to straddle lead (specify "LL")
• Frame and door leaf alignment ribs for proper hinge and door location
• 1/8" (3 mm) inset

• 5/16" (8 mm) hinge side
• Plus standard lockside clearance

• Power Transfer Preparation (EPT 2) or (EPT 10),
• Exposed Electric Contacts (E),
• Exposed Electric Switches (E1S),
• Electric Through-Wire (ETW),
• Electric Monitoring (EMN),
• Electric Through-Wire and Monitoring (ETM)

• Standard: Dril-Kwik® – #12-24 X 11/16" Flat Head Screws
• Optional: 1/2 Dril-Kwik® Screws, 1/2 wood Screws
• Additional Options Available upon request

• Standard duty for medium frequency doors. Heavy duty for high frequency doors or heavy, medium frequency doors.
• Lead lined model for hospital x-ray room doors with double row of fasteners to straddle lead (Specify "LL")
• Frame and door leaf alignment ribs for proper hinge and door location.
• 1/8" (3 mm) inset.

CLR, DBZ, BLK

79", 83", 95"

Standard and Custom

Aluminum 6063-T6

EPD: Roton Continuous Hinges Environmental Product Declaration

• Hospital Tip
• TIPIT® (see Roton accessories)

• Concealed Leaf
•

All Roton products have a lifetime warranty. When ordering electric Roton, the electric portion of the hinge has a one-year warranty.
